Camera Link Cables

Camera Link cables offered, but not limited to:

CLT-303R/L Camera Link Translators

Full-featured high-performance adapters enable use of traditional RS-422 and LVDS digital cameras with Camera Link frame grabbers.  “R” and “L” versions support parallel RS-422 and LVDS digital camera data, respectively.  Support cameras with pixel clock rates as low as 2.5 MHz and as high as 85 MHz.

CLT-351R/L Camera Link Translators

Converters enable use of newer Camera Link cameras with frame grabbers incorporating traditional RS-422 and LVDS digital interfaces. “R” and “L” versions support RS-422 and LVDS frame grabbers, respectively. Standard 68-pin AIA frame grabber interface maximizes use of existing and standard cables.

CLT-353R/L Translators

New full-featured converters enable the use of Camera Link cameras with frame grabbers and imaging systems incorporating traditional RS-422 and LVDS digital interfaces. Adapters feature an RS-232 port for camera communication. Very useful for replacing older or obsolete cameras with minimal impact to existing systems.

CLT-361 Camera Link Translator

Converter enables the use of HD-SDI cameras with Camera Link fame grabbers.  Supports 1080p, 1080i, and 720p camera video formats.

CLT-371 Translator

New adapter enables the use of Camera Link cameras with HD-SDI monitors, recorders, etc.  Supports both 1920x1080 and 1280x720 HD-SDI formats.  Very useful converter works with most base-configuration cameras.

Gigabit Ethernet Cables

Configuration is made easy with over 19 Connector types and customizations.

USB Cables

Configuration made easy.

• USB 2.0

• USB 3.0

• USB 3.1

• USB 3 Bit Maxx

• Configuration options for connectors.

S-Type IP66 Camera Housing with a Stainless Steel Arm

Stabilized stainless steel arm and IP66 camera housing for long range video applications, thermal, static, fixed, and other brick style cameras.

The S-Type professional grade outdoor video surveillance protection system is optimized for high performance static video cameras, including the latest precision HD/megapixel network based systems. The S-Type has options that couples internal active environmental control technologies with extra heavy duty construction, all at affordable prices. The S-Type comes will heavy duty wall mount bracket and is ready for installation. The Dotworkz USA made S-Type is the next generation platform offering stabilized, long life, trouble free, and IP66 no compromise camera housing solution for surveillance video projects that simply cannot afford failure or to be impeded due to summer heat, ice build up or vandalism. Non corrosive high impact thermoplastic outer shell allows for extra room to protect CCTV or IP fixed camera models, wireless radios, networking products, 3G/4G routers, or NVRs to be installed in a single airtight and temperature controlled enclosure.

STXL-CD

The Dotworkz STXL-CD is an engineered outdoor housing system that is designed to house & protect virtually all indoor box & brick camera models, especially Large Form Factor Cameras with Large High Zoom Lenses, to be turned into a complete rugged outdoor system solution.

This Extra Large housing solution is designed for a wide array of harsh & challenging environments. IP66 NEMA 4X ingress protection of housing, provides the highest levels of protection from water, dust, marine, and vandal abuse, while providing extended temperature operating range of these large form factor camera & lens combinations, by the Dotworkz Active Cooling & Heating systems integrated into this housing system.

Included is the Heavy Duty Stainless Steel wall mount arm that allows for quick, simple, & secure mounting of housing into the most common installation conditions. Other optional mounts available for a broad array of deployment mounting options. Extra Large Camera Housing for Static Cameras with Long Lenses.

Video Splitters

• Distribute video from camera to multiple frame grabbers

• Useful for parallel processing, monitoring, recording, etc.

• Multiple splitters can be cascaded to support a large number of frame grabbers

Model - Interface - Type

• Camera Link - (base-only) - 1:2

• Camera Link - (base/med/full/80-bit) - 1:2

• Camera Link - (base-only) - 1:4

• Camera Link - (base/med/full/80-bit) - 1:4

Repeaters

• Increase the separation between camera and frame grabber.

• Combine with shorter (i.e. 5m) cables to provide separation while ensuring data integrity in high-performance applications.

• CLR-102 is also a PoCL-to-Standard adapter

Model - Interface - Type

Camera Link (base-only) - Standard

Camera Link (base-only) - PoCL

Camera Link (base/med/full/80-bit) - Standard

Converters

• Convert Camera Link to/from LVDS, RS-422, HD-SDI

• Useful for replacing obsolete RS-422 & LVDS cameras and frame grabbers in existing imaging systems

• HD-SDI converters bridge industrial imaging and broadcast video

Model - Interface - Type
(i.e. frame grabber)

LVDS (EIA-644) - Camera Link

RS-422 Camera Link

Camera Link - LVDS (EIA-644)

Camera LinkRS-422

HD-SDI Camera Link

Camera LinkHD-SDI (also HDMI, DVI)

Selectors

• Electronic “switches” interface multiple cameras to one frame grabber

• Multiple selectors can be cascaded to support a large number of cameras

Model - Interface - Type

Camera Link (base-only) - 4:1

Camera Link (base/med/full/80-bit) - 4:1

Camera Simulators

• Affordable high-performance video test pattern generators

• Programmable timing, mimics most cameras

• New CLS-221 & CLS-222 support all video formats including v2.1

• PoCL versions available (CLS-212 & CLS-222)

Model - Interface - Type

Camera Link (base/med/full/80-bit) - Standard

Camera Link (base/med/full/80-bit)PoCL

Camera Link v2.1 (base/med/full/72-bit/80-bit) - Standard

Camera Link v2.1 (base/med/full/72-bit/80-bit) - PoCL

Breakout Box

• Provides access to all data transferred between camera and frame grabber

• Deserialized video data accessible via rear-panel connector

• Pair with our CLR-111A repeater to support medium, full, and 80-bit configurations

Model - Interface - Type

Camera Link (base-only) - Standard
